Frequency Range    UHF:400-470MHz
Channel capacity    16
Output power    5W
Operating Voltage    3.7V DC
Antenna Impedance    50 ohm
Working Temperature    -30°C—+60°C
Frequency Spacing    12.5/25kHz
Battery capacity    1500mAh
Color    Black
Dimension(Exclude antenna)    110x60x33mm
Weight(Include Battery)    156g/Piece
Feature
CTCSS/DCS function    50 CTCSS/105DCS
Built-in LED torch    Yes
Low battery alarm    Yes
Power saving function    Yes
Monitor function    Yes
Busy channel lock-out(BCL)    Yes
Flashlight Function    Yes
VOX function    Yes
Emergency alarm    Yes
Squelch level    Yes
Time-out timer(TOT)    Yes
Voice prompt(English and Chinese)    Yes
PC software programmable    Yes
Specification
Frequency stability    ±2.5ppm
Modulation Mode(W/N Band)    F3E
Maximum Frequency Deviation (W/N Band)    <5kHz(W), <2.5kHz(N)
Spurious Power    <=7.5 µW
Adjacent channel power    65dB (W) ,55dB (N)
Audio Distortion    5.00%
SNR    -52dB(W), -48dB(N)
Transmitting Current    <=1500mA
Sensitivity    <0.20 µ V (12dB SINAD)
Audio Power    1 W
Inter modulation Interference Resistance    >=65dB (W), >=55dB (N)
Adjacent channel Sensitivity (W/N Band)    >=65dB (W), >=55dB (N)
Receiving Current    <= 400mA
